Product Details:
Usage/Application | Industrial |
Brand | Indotech |
Model | CSM 100 |
Capacity | Dia. 100 mm |
Motor Rotation Speed | 160 Mtrs./Min. |
Power | 20 Hp |
Cooling Type | Micromist |
Automatic Chip Conveyor | Motorized Screw type Swarf Conveyor |
Country of Origin | Made in India |
Overall Size in mm | 2500 x 2700 x 1900 mm |
Approx Weight in Kg | 5400 Kgs |
Product Details:
Model Name/Number | CSM 85 |
Usage/Application | Industrial |
Brand | Indotech |
Material | Stainless Steel |
Max Cutting Thickness | Dia. 85 mm |
Automation Grade | Fully Automatic |
Country of Origin | Made in India |
Overall Size in mm | 2300 X 2500 X 1900 mm |
Approx Weight in Kg | 3200 Kgs |
Cutting Capacity | 70*40 mm |
Main Motor | 15 Hp |
Hydraulic Pump Motor | 5 |
Blade Speed (Mtr/Min) | 160 |
Blade Feed | Servo Motor And Ball Screw |
Loading Table | 1000*6000 mm |
Single Feed | 600 mm |
Multiple Feed | Possible |
Automaic Chip Conveyor | Screw Type |
Cooling | Air Compressed Oil Mist |
Machine Weight With Table | 4200 Kg |
Floor Space | 8300*2500 mm |
Product Details:
Model Name/Number | CSM-60 |
Automation Grade | Fully-Automatic, Numerically Control |
Power Consumption | 10 Hp |
No Load Speed | 160 Mtrs./Min. |
Motor | 10 Hp |
Brand | Indotech |
Cutting Capacity | Dia.60mm |
Weight | 3200Kgs |
Blade Diameter | Dia.250/285mm |
Warranty | 1 year |
Country of Origin | Made in India |
